Dual Blower Gas Extraction for High-Demand Environments.
Dual Blower Gas Extraction for High-Demand Environments.
.png?v=1782471055564&transform=resize=2570)
450 cfm dual-blower system at 39" static pressure
90 lbs. total activated carbon across 3 carbon filters
304 stainless steel, IP56 compliant cabinet
Integrated VOC sensor with USB data logging
Applications
3d printing
Pharmaceutical & medical
Printing
Beauty
Other
.png?v=1782471206980&transform=resize=2570)
GS3-500
.png?v=1782471160947&transform=resize=2570)
GS3-500
.png?v=1782471289515&transform=resize=2570)
GS3-500
Fumex GS3-500
Price
- Regular price
- $0.00
- Sale price
- $0.00
- Regular price
-
Popup heading
Some text
Couldn't load pickup availability
14 Days Return Policy
Specifications
- Construction: 304 grade brushed stainless steel, IP56 compliant, baffled, sound attenuated
- Finish: Stainless Steel
- Sound Level: 59 dBA
- Weight: 134 lbs. / 46 kg.
- Inlet Options: 3", 4" or 6"
- Wheels / Base: (4) Industrial grade wheels, two locking
- Blower Performance: 450 cfm @ 39" wc
- Blower Type: Centrifugal, direct-drive, brushless motor
- Blower Speed: Variable speed
- Motor Rating: Rated 20,000 hour+ MTBF
- Voltage Range: 90/250/1/50-60 (120v or 240v plug)
- AMP Draw: 16.0A (120v) or 10.0A (240v)
- Power Cord: Pre-wired 3 wire power cable, 9 ft. with plug
- Display / Control: Digital graphic controls, high visibility graphic display indicating blower speed, filter and unit system status
- Blower Control: Electronic variable speed blower control
- Filter Indicator / Monitoring: Electronic filter monitoring with display
- Gas Sensor: Calibrated electronic VOC gas sensor
- Digital Interface: Electronic digital interface relay for two-way communication, filter monitoring and remote start/stop control
- USB Programmability: Programmable via USB port: pressure set points, blower speeds and VOC detection
- Data Logging: System data logging: blower usage and filter service intervals, accessed via USB port
- Certifications: UL, ULC and CE/TUV compliance available
- Rubber Hose: 8 ft. 2-ply ribbed rubber hose with clamps
- IOM (Manual): Installation guide / Operations manual included
- Pre-Filter: 9" large capacity box style pre-filter, 99% efficient @ 1.0 micron, deep-pleated dimpled media (FA540B)
- Chemical Adsorption / Carbon Filter: 4" high odor / gas carbon filters (qty. 3 required), 90 lbs. total activated carbon, broad spectrum gas/odor control, bonded carbon technology, dustless construction (FA501D)
- Typical Use Cases: Inkjet printing, gluing stations, laboratory, 3D printing, copier/printing rooms, photography labs, solvents, chemical baths, beauty/nail salons
- Duty Level: Medium to heavy duty fume extraction
- Payment Terms: Net 30 days with approved credit
- FOB Point: Kennesaw (Atlanta), GA
- FA2 Relay Cable
- FA2/FA5 Relay Cable 12ft DB9
- Lumberg Connector 3' Cable
- FA122 - 1" x 4" Rectangular Hood
- FA125 - 3" Bell-Mouth Hood for 2" Hosing
- FA127 - 4" Bell-Mouth Hood for 3" Hosing
- FA126 - 2" Straight Nozzle for 2" Hosing
- FA128 - 3" Straight Nozzle for 3" Hosing
- FXA-127 - Straight Nozzle Hood
- FA151 - Bench Hood
- FAMEK 350-50 - 14" Domed Hood for 2" Articulating Arm
- FAMEK 350-75 - 14" Domed Hood for 3" Articulating Arm
- A-28-2 - 2" Articulating Arm, 3 joints, 40" Length
- A-28-3 - 3" Articulating Arm, 3 joints, 40" Length
- FXA-36-31 - 36" Stainless Steel Flexible Arm (2" Inlet)
- FXA-48-31 - 4 ft. Stainless Steel Flexible Arm (2" Inlet)
