Fumex Model FA8 Heavy Duty Air Filtration System

The Fumex Model FA8 fume extractor utilizes a high performance 3 stage hybrid filter system to capture and treat air pollutants generated during application processes. The FA8 provides high airflow and vacuum ideal for demanding applications. Operator friendly digital controls and integrated electronic gas sensor continuously monitor the system performance and display operating parameters on the high-visibility LED screen. The large capacity pre-filter extends filter change intervals and protects the large HEPA filter and gas/odor filter offering an extremely cost-effective AND efficient fume extractor system. Variable speed controls provide maximum application flexibility. Ideal for medium to heavy duty fume extraction applications.

> Cabinet: Powder Coated painted cabinet
> Baffled – sound attenuated.
> 134 lbs. / 46 kg.
> Dimensions: 54" H x 24" W x 32" D
> Front filter access

Blower Motor:
> Performance: 750 cfm @39" wc
> Variable speed controls.
> Centrifugal - direct-drive, brushless motor
> Rated 20,000 hour + mtbf

> 230/3/50-60
> Digital Graphic Display
> 8 speed electronic variable speed blower control
> Electronic individual filter monitoring with display
> Calibrated electronic VOC gas sensor
> Electronic digital interface relay for two-way
communication, filter monitoring and
remote start/stop control
> Amp Draw: 24 amps

FA8 Standard Equipment:
> Standard inlet is 6’’, optional dual 4’’ inlet
> Digital graphic controls
> (4) Industrial grade wheels
> Installation guide/Operations manual

FA8 Standard Filter Set:
> Pre-Filter:
   • Large capacity box style
   • Merv 11 rated
• Deep-pleated dimpled media
> HEPA Filter:
   • 99.97% efficient @ 0.3 micron
• Galvanized steel frame
> Gas / Odor Filter:
  • Large capacity gas/odor filter
• Provides broad spectrum gas/odor control

Image of FA8 Applications

Fumex Model FA8 Replacement Filters
